Heart Zones Foot Pod Activity Sensors

Description:

Meet your digital students where they are with the Heart Zones Move Solution for physical education and health. Provides real-time feedback with multiple sensors for engagement and motivation so students can achieve their fitness goals. Track heart rate, steps, MVPA, calories, distance, speed, time in zones, step rate, and step intensity – real data for objective grading and assessments.

The center pieces of the Step Tracking System are the Heart Zones Foot Pod Activity Sensor and the “Big Board”. The Foot Pod is an easy to use and accurate step tracker that kids love. The “Big Board” provides real time feedback that motivates and inspires students to exercise.

The Hearts Zones PE app extends to you the possibility of providing real time fitness data that allows for the assessment as well as to increase the quality and quantity of your Physical Education programs. The Hearts Zones System uses Bridge-WASP ANT+ technology that can provide greater range and reliability than Bluetooth low power (BLE) based group heart rate systems. The Bridge-WASP technology also allows simultaneous collection of data from an unlimited number of ANT+ devices concurrently.

All data is captured and stored within a cloud server-data storage system, reports using any of the data can be developed. Two reports are standard, which show Time in Zone, peak heart rate, elapsed time, average heart rate, steps, pace, and the heart rate graph or profile. Summary reports can be emailed to students and their parents with one easy push of a button.

Memory:

The Heart Zones Foot Pod sensor has a memory unit with “Smart Recording” technology that logs the detailed speed, cadence and distance data in 5 second intervals, only when striding foot motion is detected, minimizing memory usage during inactive periods. Thus, the memory can store session details of more than 5 hours at a stretch.

Wireless Data Transfer:

Workout data and performance is transferred wirelessly to a compatible IOS or Android device. No plugging in required!

Technical Specifications:

• 35 mm (L) x 25 mm (W) x 8 mm (H)
• Battery Life: 5 months for typical users Motion Analysis Capabilities



Stride Sensing Features:

• Sports Tracking Sensors with MEMS Accelerometers. Data with 95% accuracy.
• RF frequency: 2.4 Ghz
• Communication range: 2.5 m typical in lace position (dependent on receiver unit)
• Total weight (without lace clip) <8 g (including battery)
• Storage temperature: -30°C to +60°C
• Operating temperature: -10°C to +50°C
• Sensor accuracy range: 0°C to +40°C
• Complete Product Specification Sheet

Class Pack Contents:

• Heart Zones PE Software, one-time license fee (no yearly fees)
• (10, 20, or 30) Sensors/straps
• (2) Heart Zones USB Bridges
• (1) 28-port charging hub
• (1) Charging cube and USB-C or lightening adapter
• Plastic storage cases
• Installation consulting
• iPad not included
• Single sensors come with pod and strap only
